Process Control Instructions
172 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
AtuneCV1Fault BOOL CV1 Autotune has generated any of
the following faults.
AtuneCV2Fault BOOL CV2 Autotune has generated any of
the following faults.
AtuneCV3Fault BOOL CV3 Autotune has generated any of
the following faults.
AtuneCV1PVOutOfLimit BOOL Either PV or the deadtime-step
ahead prediction of PV exceeds
PVTuneLimit during CV1
Autotuning. When True, CV1
Autotuning is aborted.
AtuneCV2PVOutOfLimit BOOL Either PV or the deadtime-step
ahead prediction of PV exceeds
PVTuneLimit during CV2
Autotuning. When True, CV2
Autotuning is aborted.
AtuneCV3PVOutOfLimit BOOL Either PV or the deadtime-step
ahead prediction of PV exceeds
PVTuneLimit during CV3
Autotuning. When True, CV3
Autotuning is aborted.
AtuneCV1ModeInv BOOL The CC mode was not Manual at
start of Autotuning or the CC mode
was changed from Manual during
CV1 Autotuning. When True, CV1
Autotuning is not started or is
aborted.
AtuneCV2ModeInv BOOL The CC mode was not Manual at
start of Autotuning or the CC mode
was changed from Manual during
CV2 Autotuning. When True, CV2
Autotuning is not started or is
aborted.
AtuneCV3ModeInv BOOL The CC mode was not Manual at
start of Autotuning or the CC mode
was changed from Manual during
CV3 Autotuning. When True, CV3
Autotuning is not started or is
aborted.
AtuneCV1WindupFault BOOL CV1WindupHIn or CV1WindupLIn is
True at start of CV1 Autotuning or
during CV1 Autotuning. When True,
CV1 Autotuning is not started or is
aborted.
AtuneCV2WindupFault BOOL CV2WindupHIn or CV2WindupLIn is
True at start of CV1 Autotuning or
during CV2 Autotuning. When True,
CV2 Autotuning is not started or is
aborted.
AtuneCV3WindupFault BOOL CV3WindupHIn or CV3WindupLIn is
True at start of CV3 Autotuning or
during CV3 Autotuning. When True,
CV3 Autotuning is not started or is
aborted.
