Process Control Instructions
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 173
AtuneCV1StepSize0 BOOL CV1StepSizeUsed = 0 at start of CV1
Autotuning. When True, CV1
Autotuning is not started.
AtuneCV2StepSize0 BOOL CV2StepSizeUsed = 0 at start of CV2
Autotuning. When True, CV2
Autotuning is not started.
AtuneCV3StepSize0 BOOL CV3StepSizeUsed = 0 at start of CV3
Autotuning. When True, CV3
Autotuning is not started.
AtuneCV1LimitsFault BOOL CV1LimitsInv and CVManLimiting
are True at start of CV1 Autotuning
or during CV1 Autotuning. When
True, CV1 Autotuning is not started
or is aborted.
AtuneCV2LimitsFault BOOL CV2LimitsInv and CVManLimiting
are True at start of CV2 Autotuning
or during CV2 Autotuning. When
True, CV2 Autotuning is not started
or is aborted.
AtuneCV3LimitsFault BOOL CV3LimitsInv and CVManLimiting
are True at start of CV3 Autotuning
or during CV3 Autotuning. When
True, CV3 Autotuning is not started
or is aborted.
AtuneCV1InitFault BOOL CV1Initializing is True at start of CV1
Autotuning or during CV1
Autotuning. When True, CV1
Autotuning is not started or is
aborted.
AtuneCV2InitFault BOOL CV2Initializing is True at start of CV2
Autotuning or during CV2
Autotuning. When True, CV2
Autotuning is not started or is
aborted.
AtuneCV3InitFault BOOL CV3Initializing is True at start of CV3
Autotuning or during CV3
Autotuning. When True, CV3
Autotuning is not started or is
aborted.
AtuneCV1EUSpanChanged BOOL CV1EUSpan or PVEUSpan changes
during CV1 Autotuning. When True,
CV1 Autotuning is aborted.
AtuneCV2EUSpanChanged BOOL CV2EUSpan or PVEUSpan changes
during CV2 Autotuning. When True,
CV2 Autotuning is aborted.
AtuneCV3EUSpanChanged BOOL CV3EUSpan or PVEUSpan changes
during CV3 Autotuning. When True,
CV3 Autotuning is aborted.
AtuneCV1Changed BOOL CV1Oper is changed when in
Operation control or CV1Prog is
changed when in Program control or
CV1 becomes high/low or ROC
limited during CV1 Autotuning.
When True, CV1 Autotuning is
aborted.
