Process Control Instructions
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 197
RatioOperInv BOOL RatioOper < RatioLLimit or > RatioHLimit.
Limit value used for Ratio.
Bit 11 of Status1
CVProgInv BOOL CVProg < 0 or > 100, or < CVLLimit or >
CVHLimit when CVManLimiting is TRUE.
Limit value used for CV.
Bit 12 of Status1
CVOperInv BOOL CVOper < 0 or > 100, or < CVLLimit or >
CVHLimit when CVManLimiting is TRUE.
Limit value used for CV.
Bit 13 of Status1
CVOverrideValueIn
v
BOOL CVOverrideValue < 0 or > 100. Limit value
used for CV.
Bit 14 of Status1
CVTrackValueInv BOOL CVTrackValue < 0 or > 100. Limit value
used for CV.
Bit 15 of Status1
CVEUSpanInv BOOL The span of CVEU invalid, CVEUMax equals
CVEUMin.
Bit 16 of Status1
CVLimitsInv BOOL CVLLimit < 0, CVHLimit > 100, or CVHLimit
<= CVLLimit. If CVHLimit <= CVLLimit,
limit CV by using CVLLimit.
Bit 17 of Status1
CVROCLimitInv BOOL CVROCLimit < 0, disables ROC limiting. Bit 18 of Status1
HandFBInv BOOL HandFB < 0 or > 100. Limit value used for
CV.
Bit 19 of Status1
SampleTimeTooS
mall
BOOL Model DeadTime / DeltaT must be less than
or equal to 200.
Bit 20 of Status1
FactorInv BOOL Factor < 0. Bit 21 of Status1
ModuleGainInv BOOL ModelGain is 1.#QNAN or -1.#IND (Not A
Number), or ±1.$ ( Infinity ∞)
Bit 22 of Status1
ModelTCInv BOOL ModelTC < 0. Bit 23 of Status1
ModelDTInv BOOL ModelDT < 0. Bit 24 of Status1
RespTCInv BOOL RespTC < 0. Bit 25 of Status1
TimingModelInv BOOL TimingMode invalid. If the current mode is
not Override or Hand then set to Manual
mode.
Bit 27 of Status2
RTSMissed BOOL Only used when in Real Time Sampling
mode. Is TRUE when ABS(DeltaT -
RTSTime) > 1 millisecond.
Bit 28 of Status2.
RTSTimeInv BOOL RTSTime invalid. Bit 29 of Status2.
RTSTimeStampInv BOOL RTSTimeStamp invalid. If the current mode
is not Override or Hand then set to Manual
mode.
Bit 30 of Status2.
DeltaTInv BOOL DeltaT invalid. If the current mode is not
Override or Hand then set to Manual mode.
Bit 31 of Status2.
