Process Control Instructions
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 217
Input Parameters Data
Type
Description Values
TargetRespTC REAL Determines the speed with which the control
variables approach the target values.
Valid = 0.0 to maximum
positive float
Default = 0.0
PVTracking BOOL SP track PV request.
Set TRUE to enable SP to track PV. Ignored when
in Auto modes. SP will only track PV when all
three outputs are in manual. As soon as any
output returns to Auto, PVTracking stops.
Default = FALSE
ManualAfterInit BOOL Manual mode after initialization request.
• When TRUE, the appropriate CV(n), where (n)
can be 1, 2, or 3, will be placed in Manual
mode when CV(n)Initializing is set TRUE
unless the current mode is Override or Hand.
• When ManualAfterInit is FALSE, the CV(n)
mode will not be changed.
Default = FALSE
ProgProgReq BOOL Program Program Request.
• Set TRUE by the user program to request
Program control. Ignored if ProgOperReq is
TRUE. Holding this TRUE and ProgOperReq
FALSE can be used to lock the function block
into program control.
• When ProgValueReset is TRUE, the function
block resets the input to FALSE.
Default = FALSE
ProgOperReq BOOL Program Operator Request.
• Set TRUE by the user program to request
Operator control. Holding this TRUE can be
used to lock the function block into operator
control.
• When ProgValueReset is TRUE, the function
block resets the input to FALSE.
Default = FALSE
ProgCV1AutoReq BOOL Program-Auto mode request for CV1.
• Set TRUE by the user program to request Auto
mode.
• When ProgValueReset is TRUE, the function
block resets the input to FALSE.
Default = FALSE
ProgCV2AutoReq BOOL Program-Auto mode request for CV2.
• Set TRUE by the user program to request Auto
mode.
• When ProgValueReset is TRUE, the function
block resets the input to FALSE.
Default = FALSE
ProgCV3AutoReq BOOL Program-Auto mode request for CV3.
• Set TRUE by the user program to request Auto
mode.
• When ProgValueReset is TRUE, the function
block resets the input to FALSE.
Default = FALSE
