Process Control Instructions
234 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
Output
Parameters
Data
Type
Description Values
AtuneCV2PV2Win
dupFault
BOOL CV2WindupHIn or CV2WindupLIn is True at start of
CV2 - PV2 Autotuning or during CV2 - PV2
Autotuning. When True, CV2 - PV2 Autotuning is
not started or is aborted.
Bit 3 of AtuneCV2PV2Status
AtuneCV3PV2Win
dupFault
BOOL CV3WindupHIn or CV3WindupLIn is True at start of
CV3 - PV2 Autotuning or during CV3 - PV2
Autotuning. When True, CV3 - PV2 Autotuning is
not started or is aborted.
Bit 3 of AtuneCV3PV2Status
AtuneCV1PV2Step
Size0
BOOL CV1StepSizeUsed = 0 at start of CV1 - PV2
Autotuning. When True, CV1 - PV2 Autotuning is
not started.
Bit 4 of AtuneCV1PV2Status
AtuneCV2PV2Step
Size0
BOOL CV2StepSizeUsed = 0 at start of CV2 - PV2
Autotuning. When True, CV2 - PV2 Autotuning is
not started.
Bit 4 of AtuneCV2PV2Status
AtuneCV3PV2Step
Size0
BOOL CV3StepSizeUsed = 0 at start of CV3 - PV2
Autotuning. When True, CV3 - PV2 Autotuning is
not started.
Bit 4 of AtuneC3PV2Status
AtuneCV1PV2Limi
tsFault
BOOL CV1LimitsInv and CVManLimiting are True at start
of CV1 - PV2 Autotuning or during CV1 - PV2
Autotuning. When True, CV1 - PV2 Autotuning is
not started or is aborted.
Bit 5 of AtuneCV1PV2Status
AtuneCV2PV2Limi
tsFault
BOOL CV2LimitsInv and CVManLimiting are True at start
of CV2 - PV2 Autotuning or during CV2 - PV2
Autotuning. When True, CV2 - PV2 Autotuning is
not started or is aborted.
Bit 5 of AtuneCV2PV2Status
AtuneCV3PV2Limi
tsFault
BOOL CV3LimitsInv and CVManLimiting are True at start
of CV3 - PV2 Autotuning or during CV3 - PV2
Autotuning. When True, CV3 - PV2 Autotuning is
not started or is aborted.
Bit 5 of AtuneCV3PV2Status
AtuneCV1PV2InitF
ault
BOOL CV1Initializing is True at start of CV1 - PV2
Autotuning or during CV1 - PV2 Autotuning. When
True, CV1 - PV2 Autotuning is not started or is
aborted.
Bit 6 of AtuneCV1PV2Status
AtuneCV2PV2InitF
ault
BOOL CV2Initializing is True at start of CV2 - PV2
Autotuning or during CV2 - PV2 Autotuning. When
True, CV2 - PV2 Autotuning is not started or is
aborted.
Bit 6 of AtuneCV2PV2Status
AtuneCV3PV2InitF
ault
BOOL CV3Initializing is True at start of CV3 - PV2
Autotuning or during CV3 - PV2 Autotuning. When
True, CV3 - PV2 Autotuning is not started or is
aborted.
Bit 6 of AtuneCV3PV2Status
AtuneCV1PV2EUSp
anChanged
BOOL CV1EUSpan or PV2EUSpan changes during CV1 -
PV2 Autotuning. When True, CV1 - PV2 Autotuning
is aborted.
Bit 7 of AtuneCV1PV2Status
AtuneCV2PV2EUSp
anChanged
BOOL CV2EUSpan or PV2EUSpan changes during CV2 -
PV2 Autotuning. When True, CV2 - PV2 Autotuning
is aborted.
Bit 7 of AtuneCV2PV2Status
AtuneCV3PV2EUSp
anChanged
BOOL CV3EUSpan or PV2EUSpan changes during CV2 -
PV3 Autotuning. When True, CV3 - PV2 Autotuning
is aborted.
Bit 7 of AtuneCV3PV2Status
