Process Control Instructions
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 235
Output
Parameters
Data
Type
Description Values
AtuneCV1PV2Chan
ged
BOOL CV1Oper is changed when in Operator control or
CV1Prog is changed when in Program control or
CV1 becomes high/low or ROC limited during CV1 -
PV2 Autotuning. When True, CV1 - PV2 Autotuning
is aborted.
Bit 8 of AtuneCV1PV2Status
AtuneCV2PV2Chan
ged
BOOL CV2Oper is changed when in Operator control or
CV2Prog is changed when in Program control or
CV2 becomes high/low or ROC limited during CV2 -
PV2 Autotuning. When True, CV2 - PV2 Autotuning
is aborted.
Bit 8 of AtuneCV2PV2Status
AtuneCV3PV2Chan
ged
BOOL CV3Oper is changed when in Operator control or
CV3Prog is changed when in Program control or
CV3 becomes high/low or ROC limited during CV3 -
PV2 Autotuning. When True, CV3 - PV2 Autotuning
is aborted.
Bit 8 of AtuneCV3PV2Status
AtuneCV1PV2Time
out
BOOL Elapsed time is greater then PV2AtuneTimeLimit
since step test is started. When True, CV1 - PV2
Autotuning is aborted.
Bit 9 of AtuneCV1PV2Status
AtuneCV2PV2Time
out
BOOL Elapsed time is greater then PV2AtuneTimeLimit
since step test is started. When True, CV2 - PV2
Autotuning is aborted.
Bit 9 of AtuneCV2PV2Status
AtuneCV3PV2Time
out
BOOL Elapsed time is greater then PV2AtuneTimeLimit
since step test is started. When True, CV3 - PV2
Autotuning is aborted.
Bit 9 of AtuneCV3PV2Status
AtuneCV1PV2NotS
ettled
BOOL The PV2 is changed too much to Autotune for CV1-
PV2. When True, CV1-PV2 Autotuning is aborted.
Wait until PV2 is more stable before autotuning
CV1-PV2.
Bit 10 of AtuneCV1PV2Status
AtuneCV2PV2NotS
ettled
BOOL The PV2 is changed too much to Autotune for CV2-
PV2. When True, CV2-PV2 Autotuning is aborted.
Wait until PV2 is more stable before autotuning
CV2-PV2.
Bit 10 of AtuneCV2PV2Status
AtuneCV3PV2NotS
ettled
BOOL The PV2 is changed too much to Autotune for CV3-
PV2. When True, CV3-PV2 Autotuning is aborted.
Wait until PV2 is more stable before autotuning
CV3-PV2.
Bit 10 of AtuneCV3PV2Status
Status1 DINT Bit mapped status of the function block. A value of
0 indicates that no faults have occurred. Any
parameter that could be configured with an invalid
value must have a status parameter bit to indicate
its invalid status.
Status2 DINT Additional bit mapped status for the function block.
A value of 0 indicates that no faults have occurred.
Any parameter that could be configured with an
invalid value must have a status parameter bit to
indicate its invalid status.
Status3CV1 DINT Additional bit mapped CV1 status for the function
block. A value of 0 indicates that no faults have
occurred.
Status3CV2 DINT Additional bit mapped CV2 status for the function
block. A value of 0 indicates that no faults have
occurred.
