Allen-Bradley LOGIX 5000

Process Control Instructions
Chapter 1
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 237
Output
Parameters
Data
Type
Description Values
CV3HandFBFaulte
d
BOOL CV3 HandFB value health bad. Bit 1 of Status3CV3
CV1ProgInv BOOL CV1Prog < 0 or > 100, or < CV1LLimit or >
CV1HLimit when CVManLimiting is TRUE. Limit
value used for CV1.
Bit 2 of Status3CV1
CV2ProgInv BOOL CV2Prog < 0 or > 100, or < CV2LLimit or >
CV2HLimit when CVManLimiting is TRUE. Limit
value used for CV2.
Bit 2 of Status3CV2
CV3ProgInv BOOL CV3Prog < 0 or > 100, or < CV3LLimit or >
CV3HLimit when CVManLimiting is TRUE. Limit
value used for CV3.
Bit 2 of Status3CV3
CV1OperInv BOOL CV1Oper < 0 or > 100, or < CV1LLimit or >
CV1HLimit when CVManLimiting is TRUE. Limit
value used for CV1.
Bit 3 of Status3CV1
CV2OperInv BOOL CV2Oper < 0 or > 100, or < CV2LLimit or >
CV2HLimit when CVManLimiting is TRUE. Limit
value used for CV2.
Bit 3 of Status3CV2
CV3OperInv BOOL CV3Oper < 0 or > 100, or < CV3LLimit or >
CV3HLimit when CVManLimiting is TRUE. Limit
value used for CV3.
Bit 3 of Status3CV3
CV1OverrideValueI
nv
BOOL CV1OverrideValue < 0 or > 100. Limit value used
for CV1.
Bit 4 of Status3CV1
CV2OverrideValueI
nv
BOOL CV2OverrideValue < 0 or > 100. Limit value used
for CV2.
Bit 4 of Status3CV2
CV3OverrideValueI
nv
BOOL CV3OverrideValue < 0 or > 100. Limit value used
for CV3.
Bit 4 of Status3CV3
CV1EUSpanInv BOOL The span of CV1EU invalid, CV1EUMax equals
CV1EUMin.
Bit 5 of Status3CV1
CV2EUSpanInv BOOL The span of CV2EU invalid, CV2EUMax equals
CV2EUMin.
Bit 5 of Status3CV2
CV3EUSpanInv BOOL The span of CV3EU invalid, CV3EUMax equals
CV3EUMin.
Bit 5 of Status3CV3
CV1LimitsInv BOOL CV1LLimit < 0, CV1HLimit > 100, or CV1HLimit <=
CV1LLimit. If CV1HLimit <= CV1LLimit, limit CV1
by using CV1LLimit.
Bit 6 of Status3CV1
CV2LimitsInv BOOL CV2LLimit < 0, CV2HLimit > 100, or CV2HLimit <=
CV2LLimit. If CV2HLimit <= CV2LLimit, limit CV2
by using CV2LLimit.
Bit 6 of Status3CV2
CV3LimitsInv BOOL CV3LLimit < 0, CV3HLimit > 100, or CV3HLimit <=
CV3LLimit. If CV3HLimit <= CV3LLimit, limit CV3
by using CV3LLimit.
Bit 6 of Status3CV3
CV1ROCLimitInv BOOL Entered value for CV1ROCLimit < 0, disables CV1
ROC limiting.
Bit 7 of Status3CV1
CV2ROCLimitInv BOOL Entered value for CV2ROCLimit < 0, disables CV2
ROC limiting.
Bit 7 of Status3CV2
CV3ROCLimitInv BOOL Entered value for CV3ROCLimit < 0, disables CV3
ROC limiting.
Bit 7 of Status3CV3
CV1HandFBInv BOOL CV1 HandFB < 0 or > 100. Limit value used for CV1. Bit 8 of Status3CV1
CV2HandFBInv BOOL CV2 HandFB < 0 or > 100. Limit value used for CV2. Bit 8 of Status3CV2
