Process Control Instructions
238 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
Output
Parameters
Data
Type
Description Values
CV3HandFBInv BOOL CV3 HandFB < 0 or > 100. Limit value used for CV3. Bit 8 of Status3CV3
CV1PV1ModelGain
Inv
BOOL CV1PV1ModelGain is 1.#QNAN or -1.#IND. (Not A
Number), or ± 1.$ ( Infinity ∞ ).
Bit 9 of Status3CV1
CV2PV1ModelGain
Inv
BOOL Entered value for CV2 - PV1 Model Gain is 1.#QNAN
or -1.#IND. (Not A Number), or ± 1.$ ( Infinity ∞ ).
Bit 9 of Status3CV2
CV3PV1ModelGain
Inv
BOOL Entered value for CV3 - PV1 Model Gain is 1.#QNAN
or -1.#IND. (Not A Number), or ± 1.$
(Infinity ∞).
Bit 9 of Status3CV3
CV1PV2ModelGain
Inv
BOOL CV1PV2ModelGain is 1.#QNAN or -1.#IND. (Not A
Number), or ± 1.$ ( Infinity ∞ ).
Bit 10 of Status3CV1
CV2PV2ModelGain
Inv
BOOL Entered value for CV2 - PV2 Model Gain is 1.#QNAN
or -1.#IND. (Not A Number), or ± 1.$ ( Infinity ∞ ).
Bit 10 of Status3CV2
CV3PV2ModelGain
Inv
BOOL Entered value for CV3 - PV2 Model Gain is 1.#QNAN
or -1.#IND. (Not A Number), or ± 1.$
(Infinity ∞).
Bit 10 of Status3CV3
CV1PV1ModelTCIn
v
BOOL Entered value for CV1 - PV1 Model Time Constant <
0.
Bit 11 of Status3CV1
CV2PV1ModelTCIn
v
BOOL Entered value for CV2 - PV1 Model Time Constant <
0.
Bit 11 of Status3CV2
CV3PV1ModelTCIn
v
BOOL Entered value for CV3 - PV1 Model Time Constant <
0.
Bit 11 of Status3CV3
CV1PV2ModelTCIn
v
BOOL Entered value for CV1 - PV2 Model Time Constant <
0.
Bit 12 of Status3CV1
CV2PV2ModelTCIn
v
BOOL Entered value for CV2 - PV2 Model Time Constant <
0.
Bit 12 of Status3CV2
CV3PV2ModelTCIn
v
BOOL Entered value for CV3 - PV2 Model Time Constant <
0.
Bit 12 of Status3CV3
CV1PV1ModelDTIn
v
BOOL Entered value for CV1-PV1 Model Deadtime < 0. Bit 13 of Status3CV1
CV2PV1ModelDTIn
v
BOOL Entered value for CV2-PV1 Model Deadtime < 0. Bit 13 of Status3CV2
CV3PV1ModelDTIn
v
BOOL Entered value for CV3 - PV1 Model Deadtime < 0. Bit 13 of Status3CV3
CV1PV2ModelDTIn
v
BOOL Entered value for CV1-PV2 Model Deadtime < 0. Bit 14 of Status3CV1
CV2PV2ModelDTIn
v
BOOL Entered value for CV2-PV2 Model Deadtime < 0. Bit 14 of Status3CV2
CV3PV2ModelDTIn
v
BOOL Entered value for CV3 - PV2 Model Deadtime < 0. Bit 14 of Status3CV3
CV1PV1RespTCInv BOOL Entered value for CV1-PV1 Response Time Constant
< 0.
Bit 15 of Status3CV1
CV2PV1RespTCInv BOOL Entered value for CV2-PV1 Response Time Constant
< 0.
Bit 15 of Status3CV2
CV3PV1RespTCInv BOOL Entered value for CV3 - PV1 Response Time
Constant < 0.
Bit 15 of Status3CV3
CV1PV2RespTCInv BOOL Entered value for CV1-PV2 Response Time Constant
< 0.
Bit 16 of Status3CV1
