Allen-Bradley LOGIX 5000 User Manual

Process Control Instructions
Chapter 1
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 29
Input Parameter Data
Type
Description
HandFB1 BOOL Hand feedback state 1. This input from a field hand/off/auto station shows the
requested state of the field device. True indicates the field device is being
requested to enter the 1 state; false indicates the field device is being requested to
enter some other state.
Default is false.
HandFB2 BOOL Hand feedback state 2. This input from a field hand/off/auto station shows the
requested state of the field device. True indicates the field device is being
requested to enter the 2 state; false indicates the field device is being requested to
enter some other state.
Default is false.
FaultTime REAL Fault time value. Configure the value in seconds of the time to allow the device to
reach a newly commanded state. Set FaultTime = 0 to disable the fault timer. If
this value is invalid, the instruction assumes a value of zero and sets the
appropriate bit in Status.
Valid = any float 0.0
Default = 0.0
FaultAlarmLatch BOOL Fault alarm latch input. When true and FaultAlarm is true, latch FaultAlarm. To
unlatch FaultAlarm, set FaultAlmUnlatch to true or clear FaultAlarmLatch to false.
Default is false.
FaultAlmUnLatch BOOL Fault alarm unlatch input. Set this input to true when FaultAlarmLatch is set to
unlatch FaultAlarm. The instruction clears this input to false.
Default is false.
OverrideOnInit BOOL Override on initialization request. If this bit is true, then during instruction first
scan, the instruction is placed in Operator control with Override true and Hand
false. If ProgHandReq is true, then Override is cleared to false and Hand is set to
true.
Default is false.
OverrideOnFault BOOL Override on fault request. Set this value to true if the device should go to Override
mode and enter the Override State on a fault alarm. After the fault alarm is
removed, the instruction is placed in Operator control.
Default is false.
Out0State0 BOOL Output 0 state 0 input. This value determines the value of Output0 when the
device is in the 0 state.
Default is false.
Out0State1 BOOL Output 0 state 1 input. This value determines the value of Output0 when the
device is in the 1 state.
Default is false.
Out0State2 BOOL Output 0 state 2 input. This value determines the value of Output0 when the
device is in the 2 state.
Default is false.
Out1State0 BOOL Output 1 state 0 input. This value determines the value of Output1 when the
device is in the 0 state.
Default is false.
Out1State1 BOOL Output 1 state 1 input. This value determines the value of Output1 when the
device is in the 1 state.
Default is false.
Out1State2 BOOL Output 1 state 2 input. This value determines the value of Output1 when the
device is in the 2 state.
Default is false.
