Page #30 background image
Chapter 1
Process Control Instructions
30 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
Input Parameter Data
Type
Description
Out2State0 BOOL Output 2 state 0 input. This value determines the value of Output2 when the
device is in the 0 state.
Default is false.
Out2State1 BOOL Output 2 state 1 input. This value determines the value of Output2 when the
device is in the 1 state.
Default is false.
Out2State2 BOOL Output 2 state 2 input. This value determines the value of Output2 when the
device is in the 2 state.
Default is false.
OverrideState DINT Override state input. Set this input to indicate the state of the device when in
Override mode.
2 = Device should go to the 2 state
1 = Device should go to the 1 state
0 = Device should go to the 0 state
An invalid value sets the appropriate bit in Status.
Valid = 0 to 2
Default = 0
FB0State0 BOOL Feedback 0 state 0 input. This value determines the expected value of FB0 when
the device is in the 0 state.
Default is false.
FB0State1 BOOL Feedback 0 state 1 input. This value determines the expected value of FB0 when
the device is in the 1 state.
Default is false.
FB0State2 BOOL Feedback 0 state 2 input. This value determines the expected value of FB0 when
the device is in the 2 state.
Default is false.
FB1State0 BOOL Feedback 1 state 0 input. This value determines the expected value of FB1 when
the device is in the 0 state.
Default is false.
FB1State1 BOOL Feedback 1 state 1 input. This value determines the expected value of FB1 when
the device is in the 1 state.
Default is false.
FB1State2 BOOL Feedback 1 state 2 input. This value determines the expected value of FB1 when
the device is in the 2 state.
Default is false.
FB2State0 BOOL Feedback 2 state 0 input. This value determines the expected value of FB2 when
the device is in the 0 state.
Default is false.
FB2State1 BOOL Feedback 2 state 1 input. This value determines the expected value of FB2 when
the device is in the 1 state.
Default is false.
FB2State2 BOOL Feedback 2 state 2 input. This value determines the expected value of FB2 when
the device is in the 2 state.
Default is false.
FB3State0 BOOL Feedback 3 state 0 input. This value determines the expected value of FB3 when
the device is in the 0 state.
Default is false.
FB3State1 BOOL Feedback 3 state 1 input. This value determines the expected value of FB3 when
the device is in the 1 state.
Default is false.
