Chapter 1
Process Control Instructions
74 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
ManualAfterInit BOOL
Manual mode after initialization request. When true, the instruction is placed in Manual
mode when CVInitializing is true, unless the current mode is Override or Hand. When
ManualAfterInit is false, the instruction’s mode is not changed, unless requested to do
so.
Default is false.
ProgProgReq BOOL Program program request. Set to true by the user program to request Program control.
Ignored if ProgOperReq is true. Holding this true and ProgOperReq false locks the
instruction in Program control. When ProgValueReset is true, the instruction clears this
input to false at each execution.
Default is false.
ProgOperReq BOOL Program operator request. Set to true by the user program to request Operator control.
Holding this true locks the instruction in Operator control. When ProgValueReset is
true, the instruction clears this input to false at each execution.
Default is false.
ProgCasRatReq BOOL Program cascade/ratio mode request. Set to true by the user program to request
Cascade/Ratio mode. When ProgValueReset is true, the instruction clears this input to
false at each execution.
Default is false.
ProgAutoReq BOOL Program auto mode request. Set to true by the user program to request Auto mode.
When ProgValueReset is true, the instruction clears this input to false at each
execution.
Default is false.
ProgManualReq BOOL Program manual mode request. Set to true by the user program to request Manual
mode. When ProgValueReset is true, the instruction clears this input to false ateach
execution.
Default is false.
ProgOverrideReq BOOL Program override mode request. Set to true by the user program to request Override
mode. When ProgValueReset is true, the instruction clears this input to false at each
execution.
Default is false.
ProgHandReq BOOL Program hand mode request. Set to true by the user program to request Hand mode.
This value is usually read as a digital input from a hand/auto station. When
ProgValueReset is true, the instruction clears this input to false at each execution.
Default is false.
OperProgReq BOOL Operator program request. Set to true by the operator interface to request Program
control. The instruction clears this input to false at each execution.
Default is false.
OperOperReq BOOL Operator operator request. Set to true by the operator interface to request Operator
control. The instruction clears this input to false at each execution.
Default is false.
OperCasRatReq BOOL Operator cascade/ratio mode request. Set to true by the operator interface to request
Cascade/ Ratio mode. The instruction clears this input to false at each execution.
Default is false.
OperAutoReq BOOL Operator auto mode request. Set to true by the operator interface to request Auto
mode. The instruction clears this input to false at each execution.
Default is false.
OperManualReq BOOL Operator manual mode request. Set to true by the operator interface to request Manual
mode. The instruction clears this input to false at each execution.
Default is false.
ProgValueReset BOOL Reset program control values. When true, all the program request inputs are cleared to
false by the instruction at each execution. When true and in Operator control, the
instruction sets SPProgram = SP and CVProgram = CV.
Default is false.
