170 Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019

Chapter 8 Configuration Examples for a Kinetix Drive

7. To apply your changes and return to Axis Properties, click OK.

Figure 37 - Example 3: Feedback Only with Master Feedback, Master Feedback Dialog Box

8. From the Type pull-down menu, choose Digital AqB as the feedback

type.

9. From the Units pull-down menu, choose Rev.

Default values are completed for you.

This channel is Feedback 1 of Axis 2. It is connected to

the Aux Feedback port of the primary axis. This

Feedback-only axis is also known as the 1/2 axis.
