ALLIANCE 030 Series Installation

Model Market Gas
Altitude Burner Orifice
feet [meters] No.
inches
[mm]
Quan-
tity Part No.
055 Series T, G, A, H,
J, K, R, U
Natural Gas 2,001-4,000
[610-1,220]
13 0.1850
[4.70]
1 70684150
4,001-6,000
[1,221-1,830]
15 0.1800
[4.57]
70684148
6,001-8,000
[1,831-2,440]
17 0.1730
[4.39]
70684146
8,001-10,000
[2,441-3,050]
19 0.1660
[4.22]
70684143
T, G, A, H,
R
L.P. Gas 2,001-4,000
[610-1,220]
33 0.1130
[2.87]
70684124
4,001-6,000
[1,221-1,830]
34 0.1110
[2.82]
70684123
6,001-8,000
[1,831-2,440]
36 0.1065
[2.71]
70684120
8,001-10,000
[2,441-3,050]
38 0.1015
[2.58]
70684118
U L.P. Gas 2,001-4,000
[610-1,220]
44 0.0860
[2.18]
70684110
4,001-6,000
[1,221-1,830]
45 0.0820
[2.08]
70684109
6,001-8,000
[1,831-2,440]
46 0.0810
[2.06]
70684108
8,001-10,000
[2,441-3,050]
48 0.0760
[1.93]
70684106
J L.P. Gas 2,001-4,000
[610-1,220]
38 0.1015
[2.58]
70684118
4,001-6,000
[1,221-1,830]
40 0.0980
[2.49]
70684116
6,001-8,000
[1,831-2,440]
42 0.0935
[2.37]
70684114
8,001-10,000
[2,441-3,050]
2.3 mm 0.0906
[2.30]
70684113
Table 17
Gas Requirements
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
63 Part No. 70686701ENR4
