ALLIANCE 030 Series Installation

Eco Line Models (only available in Natural Gas)
Model Gas
Altitude Burner Orifice
feet [meters] No.
inches
[mm] Quantity Part No.
030 Series Natural Gas 2,001-4,000 [610-1,220] 3.40 mm 0.1339 [3.40] 1 70684131
4,001-6,000 [1,221-1,830] 3.30 mm 0.1299 [3.30] 70684130
6,001-8,000 [1,831-2,440] 1/8 0.1250 [3.18] 70684128
8,001-10,000
[2,441-3,050]
31 0.1200 [3.05] 70684126
T30 Series Natural Gas 2,001-4,000 [610-1,220] 3.30 mm 0.1299 [3.30] 2 70684130
4,001-6,000 [1,221-1,830] 1/8 0.1250 [3.18] 70684128
6,001-8,000 [1,831-2,440] 31 0.1200 [3.05] 70684126
8,001-10,000
[2,441-3,050]
32 0.1160 [2.95] 70684125
035 Series Natural Gas 2,001-4,000 [610-1,220] 26 0.1470 [3.73] 1 70684136
4,001-6,000 [1,221-1,830] 28 0.1405 [3.57] 70684134
6,001-8,000 [1,831-2,440] 3.50 mm 0.1378 [3.50] 70684133
8,001-10,000
[2,441-3,050]
3.30 mm 0.1299 [3.30] 70684130
T45 Series Natural Gas 2,001-4,000 [610-1,220] 22 0.1570 [3.99] 2 70684140
4,001-6,000 [1,221-1,830] 23 0.1540 [3.91] 70684139
6,001-8,000 [1,831-2,440] 26 0.1470 [3.73] 70684136
8,001-10,000
[2,441-3,050]
28 0.1405 [3.57] 70684134
055 Series Natural Gas 2,001-4,000 [610-1,220] 14 0.1820 [4.62] 1 70684149
4,001-6,000 [1,221-1,830] 16 0.1770 [4.50] 70684147
6,001-8,000 [1,831-2,440] 18 0.1695 [4.31] 70684144
8,001-10,000
[2,441-3,050]
20 0.1610 [4.09] 70684142
Table 18
Gas Requirements
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
64 Part No. 70686701ENR4
