ALLIANCE 030 Series Installation

P 380-415 50-60 3 L1, L2, L3
and ground
6 15 14 [2.5]
Table 21
T45 Series Gas Models (Total Machine)
Voltage Code Voltage Cycle Phase Wire Full Load
Amps
Recommend-
ed Circuit
Breaker Rat-
ing Amps
Wire Size
AWG [mm
2
]
X 200-240 50-60 1-3 Refer to Fig-
ure 22
12 15 14 [2.5]
N 440-480 50-60 3 L1, L2, L3
and ground
6 15 14 [2.5]
P 380-415 50-60 3 L1, L2, L3
and ground
6 15 14 [2.5]
Table 22
21 kW Standard Line 030 Series Electric Models
Voltage Code Voltage Cycle Phase Wire Full Load
Amps
Recommend-
ed Circuit
Breaker Rat-
ing Amps
Wire Size
AWG [mm
2
]
D 200-208 50-60 1 Refer to Fig-
ure 22
104 150 1/0 [50]
E 230-240 50-60 1 Refer to Fig-
ure 22
90 125 1 [35]
F 200-208 50-60 3 L1, L2, L3
and ground
61 80 4 [25]
G 230-240 50-60 3 L1, L2, L3
and ground
52 70 4 [25]
H 380 50-60 3 L1, L2, L3
and ground
33 45 8 [10]
J 400-415 50-60 3 L1, L2, L3
and ground
30 40 8 [10]
K 440 50-60 3 L1, L2, L3
and ground
29 40 8 [10]
Table 23 continues...
Electrical Requirements
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
70 Part No. 70686701ENR4
