ALLIANCE 030 Series Installation

L 460-480 50-60 3 L1, L2, L3
and ground
27 35 8 [10]
Table 23
12 kW Eco Line 030 Series Electric Models
Voltage Code Voltage Cycle Phase Wire Full Load
Amps
Recommend-
ed Circuit
Breaker Rat-
ing Amps
Wire Size
AWG [mm
2
]
D 200-208 50-60 1 Refer to Fig-
ure 1
60 80 4 [25]
E 230-240 50-60 1 Refer to Fig-
ure 1
53 70 4 [25]
F 200-208 50-60 3 L1, L2, L3
and ground
37 50 8 [10]
G 230-240 50-60 3 L1, L2, L3
and ground
33 45 8 [10]
H 380 50-60 3 L1, L2, L3
and ground
20 25 10 [6]
J 400-415 50-60 3 L1, L2, L3
and ground
18 25 10 [6]
K 440 50-60 3 L1, L2, L3
and ground
17 25 10 [6]
L 460-480 50-60 3 L1, L2, L3
and ground
16 20 12 [4]
Table 24
21 kW Standard Line T30 Series Electric Models (Per Pocket)
Voltage Code Voltage Cycle Phase Wire Full Load
Amps (Per
Pocket)
Recommend-
ed Circuit
Breaker Rat-
ing Amps
Wire Size
AWG [mm
2
]
F 200-208 50-60 3 L1, L2, L3
and ground
61 80 4 [25]
G 230-240 50-60 3 L1, L2, L3
and ground
52 70 4 [25]
Table 25 continues...
Electrical Requirements
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
71 Part No. 70686701ENR4
