ALLIANCE 030 Series Installation

H 380 50-60 3 L1, L2, L3
and ground
33 45 8 [10]
J 400-415 50-60 3 L1, L2, L3
and ground
30 40 8 [10]
K 440 50-60 3 L1, L2, L3
and ground
29 40 8 [10]
L 460-480 50-60 3 L1, L2, L3
and ground
27 35 8 [10]
Table 25
12 kW Eco Line T30 Series Electric Models (Per Pocket)
Voltage Code Voltage Cycle Phase Wire Full Load
Amps
Recommend-
ed Circuit
Breaker Rat-
ing Amps
Wire Size
AWG [mm
2
]
F 200-208 50-60 3 L1, L2, L3
and ground
37 50 8 [10]
G 230-240 50-60 3 L1, L2, L3
and ground
33 45 8 [10]
H 380 50-60 3 L1, L2, L3
and ground
20 25 10 [6]
J 400-415 50-60 3 L1, L2, L3
and ground
18 25 10 [6]
K 440 50-60 3 L1, L2, L3
and ground
17 25 10 [6]
L 460-480 50-60 3 L1, L2, L3
and ground
16 20 12 [4]
Table 26
24 kW Standard Line 035 Series Electric Models
Voltage Code Voltage Cycle Phase Wire Full Load
Amps
Recommend-
ed Circuit
Breaker Rat-
ing Amps
Wire Size
AWG [mm
2
]
D 200-208 50-60 1 Refer to Fig-
ure 22
118 150 1/0 [50]
Table 27 continues...
