ALLIANCE 030 Series Installation

E 230-240 50-60 1 Refer to Fig-
ure 22
102 150 1/0 [50]
F 200-208 50-60 3 L1, L2, L3
and ground
69 90 3 [26.7]
G 230-240 50-60 3 L1, L2, L3
and ground
59 80 4 [25]
H 380 50-60 3 L1, L2, L3
and ground
37 50 8 [10]
J 400-415 50-60 3 L1, L2, L3
and ground
34 45 8 [10]
K 440 50-60 3 L1, L2, L3
and ground
32 40 8 [10]
L 460-480 50-60 3 L1, L2, L3
and ground
30 40 8 [10]
Table 27
12 kW Eco Line 035 Series Electric Models
Voltage Code Voltage Cycle Phase Wire Full Load
Amps
Recommend-
ed Circuit
Breaker Rat-
ing Amps
Wire Size
AWG [mm
2
]
D 200-208 50-60 1 Refer to Fig-
ure 22
60 80 4 [25]
E 230-240 50-60 1 Refer to Fig-
ure 22
52 70 4 [25]
F 200-208 50-60 3 L1, L2, L3
and ground
36 45 8 [10]
G 230-240 50-60 3 L1, L2, L3
and ground
31 40 8 [10]
H 380 50-60 3 L1, L2, L3
and ground
19 25 10 [6]
J 400-415 50-60 3 L1, L2, L3
and ground
18 25 10 [6]
K 440 50-60 3 L1, L2, L3
and ground
17 25 10 [6]
L 460-480 50-60 3 L1, L2, L3
and ground
15 20 12 [4]
Table 28
Electrical Requirements
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
73 Part No. 70686701ENR4
