ALLIANCE 030 Series Installation

18 kW Medium 035 Series Electric Models
Voltage Code Voltage Cycle Phase Wire Full Load
Amps
Recommend-
ed Circuit
Breaker Rat-
ing Amps
Wire Size
AWG [mm
2
]
D 200-208 50-60 1 Refer to Fig-
ure 22
89 125 1 [35]
E 230-240 50-60 1 Refer to Fig-
ure 22
77 100 3 [26.7]
F 200-208 50-60 3 L1, L2, L3
and ground
52 70 4 [25]
G 230-240 50-60 3 L1, L2, L3
and ground
46 60 6 [16]
H 380 50-60 3 L1, L2, L3
and ground
28 35 8 [10]
J 400-415 50-60 3 L1, L2, L3
and ground
26 35 8 [10]
K 440 50-60 3 L1, L2, L3
and ground
25 35 8 [10]
L 460-480 50-60 3 L1, L2, L3
and ground
23 30 10 [6]
Table 29
9 kW Low 035 Series Electric Models
Voltage Code Voltage Cycle Phase Wire Full Load
Amps
Recommend-
ed Circuit
Breaker Rat-
ing Amps
Wire Size
AWG [mm
2
]
H 380 50-60 3 L1, L2, L3
and ground
15 20 12 [4]
J 400-415 50-60 3 L1, L2, L3
and ground
14 20 12 [4]
Table 30
Electrical Requirements
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
74 Part No. 70686701ENR4
