Illustration 7: Ceiling In-Feed Installation into Baserail Area using Integrated Power Pole (870071)
Ceiling in-feed
cable 8719(12/18) -
Position power pole
into top of 90°, Tee, or
Cross connectors
Panel support
Use wire tie to secure in-feed cable to panel support
Note: For information regarding installation of
power poles, refer to the appropriate
panel series Power Pole Installation
Instructions.
