AlphaTheta euphonia - Master Insert Connection

25
Connections
For using Master Insert
To use external effects units with Master Insert, connect as follows.
– [MASTER INSERT SEND] terminals (output) → effects unit → [MASTER INSERT
RETURN] terminals (input)
Read more: Master Insert (page 44)
Effects unit
Rear panel
