AlphaTheta euphonia - External Effects Unit Connection

24
Connections
Connecting external effects units
For using SEND FX
To use external effects units with SEND FX, connect as follows.
– [SEND FX EXTERNAL SEND] terminals (output) → effects unit → [SEND FX EXTERNAL
RETURN] terminals (input)
• Use effect units that can output effect sounds only.
Read more: SEND FX (page 38)
Effects unit
Rear panel
