Part names
Top panel
1. MIC section (page 36)
2.
Channel section (page 26)
3.
Booth section (page 35)
4.
Headphones section (page 33)
5.
Master Isolator section (page 31)
6.
SEND FX section (page 38)
7.
MASTER INSERT/(WAKE UP) button (page 44)
Turns Master Insert on and off. The button blinks when it’s turned on.
• Press while in Power Management Off mode to exit Off mode.
8.
MASTER LEVEL knob (page 26)
9.
Display section (page 10)
1 2
5
6
4
3
8
7
9
