HSMC_RX_D_P[7]
PIN_M25
LVDS RX bit 7 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[8]
PIN_R25
LVDS RX bit 8 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[9]
PIN_T25
LVDS RX bit 9 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[10]
PIN_U25
LVDS RX bit 10 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[11]
PIN_L21
LVDS RX bit 11 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[12]
PIN_N25
LVDS RX bit 12 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[13]
PIN_P25
LVDS RX bit 13 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[14]
PIN_P21
LVDS RX bit 14 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[15]
PIN_R22
LVDS RX bit 15 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[16]
PIN_T21
LVDS RX bit 16 or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[0]
PIN_D28
LVDS TX bit 0n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[1]
PIN_E28
LVDS TX bit 1n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[2]
PIN_F28
LVDS TX bit 2n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[3]
PIN_G28
LVDS TX bit 3n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[4]
PIN_K28
LVDS TX bit 4n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[5]
PIN_M28
LVDS TX bit 5n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[6]
PIN_K22
LVDS TX bit 6n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[7]
PIN_H24
LVDS TX bit 7n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[8]
PIN_J24
LVDS TX bit 8n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[9]
PIN_P28
LVDS TX bit 9n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[10]
PIN_J26
LVDS TX bit 10n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[11]
PIN_L28
LVDS TX bit 11n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[12]
PIN_V26
LVDS TX bit 12n or CMOS I/O
Depending
on JP7
HSMC_TX_D_N[13]
PIN_R28
LVDS TX bit 13n or CMOS I/O
Depending
