43
on JP7
HSMC_RX_D_N[1]
PIN_C27
LVDS RX bit 1n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[2]
PIN_E26
LVDS RX bit 2n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[3]
PIN_G26
LVDS RX bit 3n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[4]
PIN_H26
LVDS RX bit 4n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[5]
PIN_K26
LVDS RX bit 5n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[6]
PIN_L24
LVDS RX bit 6n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[7]
PIN_M26
LVDS RX bit 7n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[8]
PIN_R26
LVDS RX bit 8n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[9]
PIN_T26
LVDS RX bit 9n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[10]
PIN_U26
LVDS RX bit 10n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[11]
PIN_L22
LVDS RX bit 11n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[12]
PIN_N26
LVDS RX bit 12n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[13]
PIN_P26
LVDS RX bit 13n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[14]
PIN_R21
LVDS RX bit 14n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[15]
PIN_R23
LVDS RX bit 15n or CMOS I/O
Depending
on JP7
HSMC_RX_D_N[16]
PIN_T22
LVDS RX bit 16n or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[0]
PIN_F24
LVDS RX bit 0 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[1]
PIN_D26
LVDS RX bit 1 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[2]
PIN_F26
LVDS RX bit 2 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[3]
PIN_G25
LVDS RX bit 3 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[4]
PIN_H25
LVDS RX bit 4 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[5]
PIN_K25
LVDS RX bit 5 or CMOS I/O
Depending
on JP7
HSMC_RX_D_P[6]
PIN_L23
LVDS RX bit 6 or CMOS I/O
Depending
on JP7
