DRAM_DQ[16]
PIN_M8
SDRAM Data[16]
3.3V
DRAM_DQ[17]
PIN_L8
SDRAM Data[17]
3.3V
DRAM_DQ[18]
PIN_P2
SDRAM Data[18]
3.3V
DRAM_DQ[19]
PIN_N3
SDRAM Data[19]
3.3V
DRAM_DQ[20]
PIN_N4
SDRAM Data[20]
3.3V
DRAM_DQ[21]
PIN_M4
SDRAM Data[21]
3.3V
DRAM_DQ[22]
PIN_M7
SDRAM Data[22]
3.3V
DRAM_DQ[23]
PIN_L7
SDRAM Data[23]
3.3V
DRAM_DQ[24]
PIN_U5
SDRAM Data[24]
3.3V
DRAM_DQ[25]
PIN_R7
SDRAM Data[25]
3.3V
DRAM_DQ[26]
PIN_R1
SDRAM Data[26]
3.3V
DRAM_DQ[27]
PIN_R2
SDRAM Data[27]
3.3V
DRAM_DQ[28]
PIN_R3
SDRAM Data[28]
3.3V
DRAM_DQ[29]
PIN_T3
SDRAM Data[29]
3.3V
DRAM_DQ[30]
PIN_U4
SDRAM Data[30]
3.3V
DRAM_DQ[31]
PIN_U1
SDRAM Data[31]
3.3V
DRAM_BA[0]
PIN_U7
SDRAM Bank Address[0]
3.3V
DRAM_BA[1]
PIN_R4
SDRAM Bank Address[1]
3.3V
DRAM_DQM[0]
PIN_U2
SDRAM byte Data Mask[0]
3.3V
DRAM_DQM[1]
PIN_W4
SDRAM byte Data Mask[1]
3.3V
DRAM_DQM[2]
PIN_K8
SDRAM byte Data Mask[2]
3.3V
DRAM_DQM[3]
PIN_N8
SDRAM byte Data Mask[3]
3.3V
DRAM_RAS_N
PIN_U6
SDRAM Row Address Strobe
3.3V
DRAM_CAS_N
PIN_V7
SDRAM Column Address Strobe
3.3V
DRAM_CKE
PIN_AA6
SDRAM Clock Enable
3.3V
DRAM_CLK
PIN_AE5
SDRAM Clock
3.3V
DRAM_WE_N
PIN_V6
SDRAM Write Enable
3.3V
DRAM_CS_N
PIN_T4
SDRAM Chip Select
3.3V
Table 4-29 Flash Pin Assignments
Signal Name
FPGA Pin No.
Description
I/O Standard
FL_ADDR[0]
PIN_AG12
FLASH Address[0]
3.3V
FL_ADDR[1]
PIN_AH7
FLASH Address[1]
3.3V
FL_ADDR[2]
PIN_Y13
FLASH Address[2]
3.3V
FL_ADDR[3]
PIN_Y14
FLASH Address[3]
3.3V
FL_ADDR[4]
PIN_Y12
FLASH Address[4]
3.3V
FL_ADDR[5]
PIN_AA13
FLASH Address[5]
3.3V
FL_ADDR[6]
PIN_AA12
FLASH Address[6]
3.3V
FL_ADDR[7]
PIN_AB13
FLASH Address[7]
3.3V
FL_ADDR[8]
PIN_AB12
FLASH Address[8]
3.3V
FL_ADDR[9]
PIN_AB10
FLASH Address[9]
3.3V
FL_ADDR[10]
PIN_AE9
FLASH Address[10]
3.3V
FL_ADDR[11]
PIN_AF9
FLASH Address[11]
3.3V
FL_ADDR[12]
PIN_AA10
FLASH Address[12]
3.3V
FL_ADDR[13]
PIN_AD8
FLASH Address[13]
3.3V
FL_ADDR[14]
PIN_AC8
FLASH Address[14]
3.3V
