Troubleshooting
R SERIES: Hand Lowering of Rear Cushion
If the rear cushion does not come down when pressing the switch, and its fuse is not blown:
1. Unscrew the bolt at the top of the actuator. It is located under the cushion at the centre
towards the back.
2. Once the actuator is resting on the floor, pull on the vertical panel that supports the
cushion.
3. The cushion will tilt by itself.
If you have to manually raise the cushion, push on the panel until it is vertical, reposition the
actuator and temporarily put the bolt back in its place.
R SERIES: Hand Lowering of Electric Roof
The manual lowering of the electric roof should always be done by 2 or 3 persons, never alone.
1. Lower rear cushion. If the lowering of the rear cushion cannot be done electrically, see
Manually Lowering Rear Cushion.
2. Cut two pieces of wood (2″ × 4″) that you will fit between the bumper and both rear
corners of the roof. The two persons helping should always keep an eye on these
pieces of wood to make sure they remain in place.
3. With a 9/16” socket unscrew the bolt holding the top of the right actuator (motor) to
the windowed structure. Make sure that both rear corners are well secured with the
pieces of wood before proceeding with this operation. This is very important because
if one or both pieces of wood holding the roof slide off, the roof would lose all support
and fall on the person inside, causing injuries to this person. Furthermore, by falling
on its cylinder, the roof could sustain considerable damage.
4. Screw in the chromed section of the cylinder as soon as you have removed the bolt.
The chromed section will screw completely inside the black part of the cylinder. In the
event that the chromed section cannot be screwed in, remove the bottom bolt and
move the cylinder on the bed or the floor so that it does not hinder the lowering on
the roof. If it is impossible to move the cylinder so that it does not hinder the lowering
of the roof, cut the electrical wire about 6 inches from the cylinder and remove it
completely.
5. Repeat steps 3 and 4 for left side.
6. Go outside and, with the help of the two persons assisting you, go to the rear and hold
the roof securely. Remove the pieces of wood supporting it.
CAUTION: MAXIMUM SUPPORTED
WEIGHT
IS
91 KG
(200 LBS.)
7. Manually lower the roof.
8. Reinstall actuator (cylinders) once the roof is completely closed. This operation will
lock the roof down. If unable to lock one of the actuators, one will suffice.
9. Upon your return have the roof fixed.
