28
Two LPG Bottles
The ALTO F2114, A2124 F2414 come standard with two bottles of propane (ALTO R1713/1723
and F1743 can also be equipped this way as an option).
The proper way to remove bottles on this double bottle set is the following:
1. Close the valve on the bottle to be removed (photo G-1);
2. Unscrew and removed the supply hose from the bottle (photo G-2) ;
3. Unscrew the wing nut on top of threaded rod (photo G-4.1) ;
4. Remove the bracket to free the bottle to be removed (photo G-4.2).
ATTENTION: Do NOT tow your ALTO equipped with a double set of bottles when only one
is present.
The proper way to install bottles:
1. Place the bottle in its place on the front of your trailer;
2. Secure the bottle by replacing bracket and tightening retaining bolt;
3. Screw the supply hose back on the bottle, and hand tighten.
PHOTO G-1
Propane tank valve and tap
PHOTO G-2
Supply hose
PHOTO G-3
Single propane tank
retaining bolt
