Alto F2114 - Windows

54
Windows
The windows in your travel trailer are either safety glass or acrylic plastic.
R SERIES Both side windows have a sliding sash lower section.
NOTE: Rear window is designed for emergency exit.
R SERIES
To open:
1. Free velcroed screen bottom (photo K-8.1) to access locks;
2. Turn all four latches ¼ turn to release (photo K-8.2);
3. Push window to desired position and tighten hold-open arms.
F SERIES
To open:
1. Turn the four latches ¼ turn to release (photo K-9.1).
2. Push out until the top-hinged window to the desired position and tighten hold-open arms.
To close the window:
1. Reverse this procedure.
2 1
PHOTO K-8
Window latches
PHOTO K-9
Four window latches
