P.
SPECIFICATIONS
NOTE: All weights listed in the Specification Chart are checked and updated throughout the model
year. Your production trailer may vary from the listed weights.
Weight
For precise cargo capacity read the Cargo Carrying Capacity tag on side of trailer. The “WEIGHT
OF CARGO SHOULD NEVER EXCEED” numbers shown on the Cargo Carrying Capacity tag on your
trailer is the maximum weight of cargo you can load and carry in your specific trailer as built with
its options.
This tag is located on the driver side of the trailer.
The Tire & Loading information tag lists the Size and Cold Inflation Pressure of the tires on your
trailer, the weight of your trailer as manufactured, and the Gross Vehicular Weight Rating
(GVWR).
The Vehicle Manufacturing Tag lists the size of tires and wheel rims, Maximum Cold Inflation
pressures, the Vehicle Identification Number (VIN), and Gross Axle ratings (GAWR).
Gross Vehicular Weight Rating (GVWR): is the maximum permissible weight of this trailer when
fully loaded. It includes all weight at the trailer axle and tongue or pin.
Gross Axle Weight Rating (GAWR): is the value specified as the load-carrying capacity of a single
axle system, as measured at the tire-ground interfaces.
As an additional safety margin on ALTO R/F17XX the axle has a GAWR of 3500 lb (1587 kg), well
over the 2700 lb (1224 kg )GVWR.
Tires
TIRE SIZE
• ALTO 17xx : ST175/80R13
• ALTO 21xx : ST205/75R15
• ALTO 2414 : ST205/75R15
MAXIMUM WEIGHT PER TIRE
Model Weight in kg Weight in lbs
1713, 1723, 1743 per tire 712 kg 1570 lb
2114 per tire 825 kg 1820 lb
2124 per tire 975 kg 2150 lb
2414 per tire 825 kg 1820 lb
TIRE INFLATION (PSI) COLD
Model Tire size Cold pressure in
kilopascals
Cold pressure in pound-force
per square inch (psi)
1713, 1723, 1743 ST175/80R13 448 kPa 65 psi
2114 ST205/75R15 344 kPa 50 psi
2124 ST205/75R15 448 kPa 65 psi
2414 ST205/75/R15 344 kPa 50 psi
