DIMENSIONS AND CAPACITIES
UNITS USED: METRE (INCH)
AND LITRE
R1713 R1723 F1743 F2114* A2124* F2414*
OVERALL LENGTH 5.26 m
(207)
5.26 m
(207)
5.41 m
(213)
6.48 m
(255)
6.48 m
(255)
7.30 m
(288)
OVERALL WIDTH 2.11 m
(83)
2.11 m
(83)
2.18 m
(86)
2.18 m
(86)
2.18 m
(86)
2.18 m
(86)
EXTERIOR HEIGHT (ROOF
LOWERED)
2.11 m
(83)
2.11 m
(83)
2.42 m
(95.5)
2.54 m
(101.5)
2.54 m
(101.5)
2.54 m
(104.5)
EXTERIOR HEIGHT (ROOF
RAISED)
2.56 m
(101)
2.56 m
(101)
- - - -
INTERIOR HEIGHT (ROOF
LOWERED)
1.62 m
(64)
1.62 m
(64)
1.93 m
(76)
1.93 m
(76)
1.93 m
(76)
1.93 m
(76)
INTERIOR HEIGHT (ROOF
RAISED)
2.08 m
(82)
2.08 m
(82)
- - - -
WHEEL BASE (BETWEEN
COUPLING AND CENTRE OF
WHEELS)
3.04 m
(120)
3.04 m
(120)
3.12 m
(123)
3.91 m
(154)
3.91 m
(154)
3.91 m
(154)
MAIN BED (72 × 76) (60 × 76) (60 × 81) (80 × 81)
irregular
(80 × 81)
irregular
(80 × 81)
irregular
MAIN BED TWIN BEDS (2x27x76) (1x27x76) - - - -
FRONT BED (36 × 81) (36 × 81) (36 × 81) (60 × 81) (52 × 72)
irregular
(60 × 81)
POTABLE WATER TANK (L) 60 60 60 100 100 100
GREY WATER TANK (L) 60 60 60 90 90 90
BLACK WATER TANK (L) 46 46 46 54 54 54
NOTE: All weights listed in the Specification Chart are checked and updated throughout the
model year. Your production trailer may vary from weights listed. These weights are for
base models without options.
* The ALTO F2114, A2124 and F2414 have a height of 2.6 metres (104 inches/8.7 feet) with
MaxxFan and 2.73 metres (107.5 inches/8.9 feet) with a TV antenna. The ALTO F2414 with
rooftop air conditioner is 2.81 metres (111 inches/9.25 feet) high.
