DE-3000 IOI 7-17
All rights reserved © ALTRONIC, LLC 2017
17
PRESS TO
EDIT PID
DEADBAND
ENTER
RUNNING
EDIT SETPOINTS
EDIT CONTROLS
~EDIT PID DEADBAND
CALIBRATION
PRESS TO
ACCEPT OR
GO TO NEXT
VALUE
ENTER
PRESS TO
CHANGE
VALUE
↑
UNITS
RUNNING
PID #1
DEADBAND 1.0 PSIG
PID #2
DEADBAND 0.2 PSIG
9.10 The TEST home screen is entered by pressing the TEST key. The TEST mode
disarms all outputs and may only be entered from the RUNNING mode. The
test time remaining is shown on the top line. See section 13.0 TEST MODE
SCREENS for more information.
PRESS
TO TEST
TEST
TEST MODE
STATUS TEST 600 SEC
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
9.11 If a fault condition occurs, the FAULT message for the first faulted channel will
appear on the display and will remain there until it is acknowledged. The numbers
one through two, after AL (alarm), shows the output switch that is faulted. To view
the first fault screen again, press the VIEW CHAN key. If all of the faulted sensors
have been cleared and the RESET key is pressed, the class B, C and output timers
will reset and the display will return to the TIMERS ACTIVE home screen.
1
ST
FAULT
STATUS FAULT AL12
1ST FAULT
CHAN 24
LOW OIL PRESSURE
EDIT SETPOINTS
EDIT PRIM. CONTROL
~EDIT PID DEADBAND
CALIBRATION
PID #1
DEADBAND 1.0 PSIG
PID #2
DEADBAND 0.2 PSIG
STATUS TEST 600 SEC
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
STATUS FAULT AL12
1ST FAULT
CHAN 24
LOW OIL PRESSURE
NOTE: THE RESET FUNCTION CAN
ALSO BE IMPLEMENTED BY USING
THE EXTERNAL HARDWARE.RESET/
AUTO START INPUT AVAILABLE ON THE
TERMINAL MODULE. THE BEHAVIOR OF
THE CONTROLLER AND DISPLAY WILL BE
DETERMINED BY THE PROGRAMMING
SELECTIONS MADE WHEN CONFIGUR-
ING THE UNIT.
