DE-3000 IOI 7-17
All rights reserved © ALTRONIC, LLC 2017
18
RETURNS TO
FAULT HOME
SCREEN
ESC
1
ST
FAULT
STATUS FAULT AL12
SPEED 0 RPM
SUCTION 102.3 PSIA
DISCHARGE 0 PSIG
PRESS
TO CLEAR
FAULTS,
RESET
TIMERS AND
OUTPUTS
RESET
PRESS TO
RETURN TO
1ST FAULT
SCREEN
VIEW
CHAN
9.12 The MANUAL STOP message will supersede all of the above home screens if the
STOP key is pressed.
PRESS TO
STOP
STOP
MANUAL STOP
STATUS MANUAL STOP
SPEED 0 RPM
SUCTION 102.3 PSIA
DISCHARGE 0 PSIG
10.0 VIEW PROCESS INFORMATION SCREENS
10.1 The VIEW PROCESS screen displays which digital outputs on the terminal board
are on/off. It also displays either a bargraph or graphing, depending on the type
of display being used.
STATUS RUNNING
SPEED 1000 RPM
SUCTION 102.3 PSIA
DISCHARGE 200 PSIG
RUNNING
PRESS
VIEW
PRESS
VIEW
TERM. OUTPUT ENABLED
NO OUTPUTS ENABLED
RUNNING
STATUS FAULT AL12
SPEED 0 RPM
SUCTION 102.3 PSIA
DISCHARGE 0 PSIG
STATUS MANUAL STOP
SPEED 0 RPM
SUCTION 102.3 PSIA
DISCHARGE 0 PSIG
NOTE: THE STOP FUNCTION CAN ALSO
BE IMPLEMENTED REMOTELY BY USING
THE EXTERNAL STOP INPUT AVAIL-
ABLE ON THE TERMINAL MODULE. THE
BEHAVIOR OF THE CONTROLLER AND
DISPLAY WILL BE IDENTICAL TO THAT
OBTAINED BY PRESSING THE LOCAL
STOP KEY ON THE DISPLAY MODULE.
TERM. OUTPUT ENABLED
NO OUTPUTS ENABLED
