DE-3000 IOI 7-17
All rights reserved © ALTRONIC, LLC 2017
34
The time and date will be displayed with the selection arrow pointing to the time.
The hours, and minutes can be edited separately, AM and PM follow the hours.
With the selection arrow pointing to the hours, use the
↑
UNITS or
↓
UNITS keys
to increase or decrease the hours. Press ENTER to save the new hour setting;
the selection arrow will point to the minutes. Use the same procedure to edit the
minutes. Use the NEXT key to move through the time and date screen without
making a permanent change in memory.
TIME: ~11:30 AM
DATE: 09-03-2012
RUNNING
The date is shown as month-day-year. The month, day and year can be edited
separately. With the selection arrow pointing to the month, use the
↑
UNITS or
↓
UNITS keys to increase or decrease the month. Press ENTER to save the new
month setting; the selection arrow will point to the day. Use the same procedure
to edit the day and the year.
TIME: 11:30 AM
DATE: ~09-03-2012
RUNNING
15.14 To view or edit the communications setup, select COMMUNICATIONS from the
menu and press ENTER.
COMMUNICATIONS
NODE ~ 1
PORT 1 ASCII
PORT 3 MODBUS 38.4
RUNNING
Use the NEXT key to select node, port 1 or port 3; then use the UP or DOWN
arrow keys to change the node number from 1 to 99 and port 1 and port 3 from
ASCII to MODBUS. Press ENTER to save selection.
TIME: ~11:30 AM
DATE: 09-03-2012
TIME: 11:30 AM
DATE: ~09-03-2012
COMMUNICATIONS
NODE ~ 1
PORT 1 ASCII
PORT 3 MODBUS 38.4
