DE-3000 IOI 7-17
All rights reserved © ALTRONIC, LLC 2017
33
A diamond will replace the arrow in front of the selected output switch. An arrow
will precede the delay time indicating a change can be made to the delay time
of the selected output. Use the
↑
UNITS or
↓
UNITS keys to increase or decrease
the value by one or use the
→
TENS or
←
TENS key to increase or decrease the
value by ten. The ENTER key accepts the change and advances the pointer to
select either N/O, N/C or IGN.
PRESS TO
ACCEPT THE
CHANGE IN
VALUE
ENTER
OUTPUT 1 ©2
DELAY TIME ~6 SEC
N/O N/C ©IGN
RUNNING
The selection arrow replaces the diamond indicating a change can be made.
The selected output switch can be configured for N/O (normally-open), N/C
(normally-closed), or IGN (ignition module 691124).
An output switch configured for normally-open will be open in the normal run
state and close upon a fault.
An output switch configured for normally-closed will be closed in the normal run
state and will open upon a fault or loss of 12-24Vdc input power.
An output switch configured for the ignition module will be open during normal
run and will close upon a fault or loss of 12-24Vdc input power. Use the NEXT
key to make a selection and press ENTER to save.
OUTPUT 1 ©2
DELAY TIME ©6 SEC
N/O N/C ~IGN
RUNNING
THEN
PRESS
ENTER
PRESS
NEXT
Upon pressing the ENTER key, a diamond will replace the selection arrow. To
view or edit the next output number, press the NEXT or
→
TENS or
←
TENS keys
until the arrow points to the desired output number and repeat the process.
15.13 To view or edit the time and date, select EDIT SAFETY SHUTDOWN from the
main menu. Select MORE MENUS from the following menu. Finally, select EDIT
TIME AND DATE from the last menu.
OUTPUT CONFIG.
~EDIT TIME AND DATE
COMMUNICATIONS
TO PREVIOUS MENU
RUNNING
OUTPUT 1 ©2
DELAY TIME ~6 SEC
N/O N/C ©IGN
NOTE: THE IGN SELECTION IS INTENDED
FOR THE ALTRONIC OUTPUT MODULE
691124 ONLY. THE IGN SELECTION CAN
BE MADE FOR OUTPUT SWITCH NUM-
BERS 1 AND 2 ONLY.
OUTPUT 1 ©2
DELAY TIME ©6 SEC
N/O N/C ~IGN
OUTPUT CONFIG.
~EDIT TIME AND DATE
COMMUNICATIONS
TO PREVIOUS MENU
