DE-3000 IOI 7-17
All rights reserved © ALTRONIC, LLC 2017
32
~OUTPUT CONFIG.
EDIT TIME AND DATE
COMMUNICATIONS
TO PREVIOUS MENU
RUNNING
OUTPUT~ 1 2
DELAY TIME 0 SEC
N/O N/C IGN
RUNNING
A selection arrow pointing to output 1, along with its delay time and a dia-
mond showing whether it is configured for N/O (normally-open), N/C (normally-
closed), or IGN (ignition output module 691124), will be shown. To view the
configuration, use the NEXT or
→
TENS or
←
TENS keys to place the selection
arrow in front of the output to be viewed. The time delay and output state will be
shown for each output.
OUTPUT~1 2
DELAY TIME 0 SEC
N/O N/C ©IGN
RUNNING
To edit a configuration, use the NEXT or
→
TENS or
←
TENS keys to place the
selection arrow in front of the desired output and press the ENTER key. The
selection arrow will point to the delay time. Each output switch can have its own
activation delay time from 0 to 999 seconds. An output switch with a delay time
of 0 seconds will trip immediately upon a fault. If a delay time is set for an out-
put switch, the output will trip following a fault plus the delay time selected. This
allows, for example, a delay time between when the fuel valve trips on output 1
and when the ignition shorts on output 2.
OUTPUT 1 ~2
DELAY TIME 3 SEC
N/O N/C ©IGN
RUNNING
THEN
PRESS
ENTER
PRESS
NEXT
~OUTPUT CONFIG.
EDIT TIME AND DATE
COMMUNICATIONS
TO PREVIOUS MENU
OUTPUT~ 1 2
DELAY TIME 0 SEC
N/O N/C IGN
OUTPUT~1 2
DELAY TIME 0 SEC
N/O N/C ©IGN
OUTPUT 1 ~2
DELAY TIME 3 SEC
N/O N/C ©IGN
