Amazone Hektor - 3 Model Overview; Technical Data

Model overview / Technical data
3 Model overview / Technical data
Type Number of
shares
Interbody
clearance
Underbeam
clearance
Weight
Stone release: Shear pin (double-cut shear bolt):
Hektor 5+1-1000 6 furrows
100 cm 82 cm
3,090 kg
Hektor 6-1000 6 furrows 3,070 kg
Hektor 6+1-1000 7 furrows 3,360 kg
Hektor 7-1000 7 furrows 3,340 kg
Hektor 7+1-1000 8 furrows 3,630 kg
Hektor 8-1000 8 furrows 3,610 kg
Stone release: NON STOP hydraulic (compact accumulator):
Hektor 5+1-1000 S 6 furrows
100 cm 82 cm / 78 cm
3,500 kg
Hektor 6-1000 S 6 furrows 3,480 kg
Hektor 6+1-1000 S 7 furrows 3,830 kg
Hektor 7-1000 S 7 furrows 3,810 kg
Optional equipment
Plough body WY400 / WL430 / WXH400 / WXL430 / WX400 / WX400 PE
UN400 / UN430 / slatted body WST430
Share systems
• RH share 430 - (NOT for WXH400 body)
• Share system with exchangeable tip 430M
Lower link axle Cat. 3 / 4N
Working width
adjustment
for each body 38-42-46-50 cm, mechanically adjustable
Hektor BAG0186.1 07.19
23
