Amazone Hektor - Uncoupling the Implement

Coupling and uncoupling the implement
5.2 Uncoupling the implement
Put down the plough on solid level ground.
1. Block the ball valves on the turning cylinder.
2. Close the stop taps for the track
adjustment.
3. Move both jacks into parking position, peg
with pins and secure with spring cotter pins.
4. Lower the implement and thus relieve the
running gear wheel.
5. Put down the implement from transport
position onto the two jacks.
6. Close the stop tap for the lifting hydraulic
system (1)
7. Lower the 3-point frame until the top link is
relieved.
8. Uncouple the top link.
9. Slightly raise the 3-point frame with the
tractor lower link.
10. Secure the 3-point frame with the chain.
11. Uncouple the supply lines.
12. Uncouple the lower link.
Hektor BAG0186.1 07.19
31
