Cleaning, maintenance and repair
10.7 Checking the support wheel
• Regularly check
ο that wheel nuts are firmly seated.
ο tyre inflation pressure.
Required tyre inflation pressure: 2,5 bar
Required tightening torque for wheel nuts / bolts: 600Nm
10.7.1 Changing the support wheel
1. Put down the coupled implement in working
position on the shares.
1.
Lift the support wheel from the ground using
a lifting jack.
2. Loosen the axle attachment bolts on both
sides.
3. Remove the wheel from the fork
4. Loosen the bolts that connect the rim to the
running axle
5. Change the tyres
6. Install the rim and axle attachment bolts in
the reverse sequence.
Hektor BAG0186.1 07.19
57
