7.4 Adjusting the pitch
The plough must be horizontal during operation.
Adjust the pitch symmetrically on the left and
right using the setting spindles (1).
The landsides and plough beams (2) must be
perpendicular to the ground.
To be able to turn the setting spindles, briefly
apply pressure to the turning cylinder.
This relieves the spindles.
(1) Rear pitch stops
Hektor BAG0186.1 07.19
39
