Cleaning, maintenance and repair
10.1 Lubrication schedule
All lubrication points (see lubrication schedule) are to be lubricated
regularly every 10 operating hours.
Lubricate / grease the implement at the specified
intervals (operating hours h).
Lubrication points on the machine are indicated
with a sticker.
Carefully clean the lubrication points and grease
gun before lubrication so that no dirt is pressed
into the bearings. Press the dirty grease
completely out of the bearings and replace with
new grease!
Overview of lubrication points
Lubrication point Number Type of lubrication
(1) 1 Grease nipple
(2) 1 Grease nipple
(3) 2 Grease nipple
(4) 2 Grease nipple
(5) 1 Grease nipple
(6) 1 Grease nipple
(7) 2 Grease nipple
(8) 1 Grease nipple
(9) 1 Grease nipple
(10) 1 Grease nipple
(11) 1 Grease nipple
(12) 1 Grease nipple
(13) 2 Grease nipple
(14) 2 Grease nipple
(15) 2 Grease nipple
(16) 1 Grease nipple
(17) 1 lubricate
