AMERITEC AM-48 - Send Continuous Variable Tone; Send Set of Slope Tones

AM-48 Test Set (18-0015) Operating Instructions
0015-S07
7-1
9
7.15 Send Continuous Variable Tone
1. See Figure 7-2. Set switches per the SWITCH SETUP illustration,
and set the SEND cursor per the lower menu illustration.
2. Go to the “LEVL” display and set the desired level value.
3. Go to the “FREQ” display and set the desired frequency value.
7.16 Send Set of Slope Tones
1. See Figure 7-3. Set switches per the SWITCH SETUP illustration,
and set the SEND cursor per the upper menu illustration.
2. Go to the “LEVL” display and set the desired level value.
3. Go to the initial display and note that the frequencies 404 Hz,
1004 Hz, and 2804 Hz (404 Hz, 1004 Hz, 2004 Hz, and 3004 Hz
for AM-48E) are sent in a cycle @ 5 seconds.
