Self-Test Instructions (18-0015) AM-48 Test Set
0015-S055-4
The FILTER menu cursor (controlled by Switch 4) will default to
C-MSG (PSHO
for AM-48E) when power is turned on. Leave the
cursor in this position for all the tests in this section.
5.3 Quiet Send Mode
Quiet Send Mode switch settings and display are depicted in Figure
5-3.
A. Verify that the SEND menu cursor is in QUIET (default position
when power is first turned on). Rock Switch 6 if necessary to
move cursor to QUIET.
B. Verify that the MEASURE menu cursor is in L/F (default position
when power is first turned on). Rock Switch 5 if necessary to
move cursor to L/F (level/frequency).
C. Display should read “UNDR” with units “DBM” and “HZ”.
D. Rock Switch 5 to move cursor to NOISE (to the right of L/F
).
E. Display should read “UNDR” with units of “DBRN” (“DBM” for
AM-48E).
Ameritec
PERSONAL TRANSMISSION TEST SET
MODEL AM-48
SEND MEASURE FILTER
ON
ABS
REL
SEND
ON/
OFF
∇
∇
∇
DAMP
∇
∇
OFF
SEL
900Ω
600Ω
∇
∇
∇
SEL
∇
∇
SEL
∇
∇
3K C-MSG
15K PROG
QUIET 1004 VAR
PAR
L/F
PAR3 TONE SWEEP
NOISE NOISE S/N
HOLD
TONE
IMPLS ØJTR JTR TRANS
∇
∆
•
•
MON RCV
MON SND
TALK
∇
TERM
∇
BRDG
∇
∇
•
4W
•
TONE
PULSE
ON HK
∇
∇
•
MF
DTMF
SHIFT
ETR/NEXT
ETR/PREV
CANCEL
STOPSTART
4W/2W
SND
4W
RCV
+ / -
∇
∇
∇
∇
∇
2W
4W REV
MIC
VOL
PRT EAR
DC
9V
∇
∇
∇
•
SF SKP
NOR
X TONE
∇
RCL/STO
∇
∇
•
PRINT
∇
21 A3
54 B6
87 C9
0
*
D#
5
B
D
A
6
Set L/F
Set NOISE
Set QUIET
A
B
C
3K C-MSG
15K PROG
QUIET
DBM
HZ
1004 VAR
PAR
L/F
PAR3 TONE SWEEP
NOISE NOISE S/N
HOLD
TONE
IMPLS ØJTR JTR TRANS
∇
∆
QUIET
darkened
L/F darkened
A
D
E
3K C-MSG
15K PROG
QUIET
DBRN
1004 VAR
PAR
L/F
PAR3 TONE SWEEP
NOISE NOISE S/N
HOLD
TONE
IMPLS ØJTR JTR TRANS
∇
∆
QUIET
darkened
NOISE darkened
Figure 5-3. Quiet Send Mode Self Test
