AMERITEC AM-48 - Table 7-3. User-Programmable Parameter Values Stored in Memory

AM-48 Test Set (18-0015) Operating Instructions
0015-S07
7-11
Table 7-3. User-Programmable Parameter Values Stored in Memory
VOLATILE MEMORY
PARAMETER DEFAULT LEVEL
Level 00.0 dBm
Variable Frequency 1004 Hz
Variable Sweep Start Frequency 204 Hz
Stop Frequency 19,904 Hz
Step 100 Hz
Rate 1.0 sec
Jitter Bandpass Range 20 Hz – 300 Hz
NON-VOLATILE MEMORY
PARAMETER FACTORY SETTINGS
Dial Level (DTMF and MF) -10.0 dBm
Blanking Interval 125 ms
Time Off with Momentary Power 16 minutes
10 Momentary Frequencies
(with Volatile Memory Level)
Not Applicable
10 Test Setups
(Stored on Number Keys
using <RCL/STO>)
Not Applicable
Timed Test Parameters
Duration of Timed Test
Impulse Noise Delta
Impulse Noise Threshold
Phase Hit Threshold
Gain Hit Threshold
Timed Test Results
Time Elapsed
Low Impulse Count
Middle Impulse Count
High Impulse Count
Noise
Phase Hit Count
Gain Hit Count
Dropouts
Phase Locked Loop Frequency
Not Applicable
Not Applicable
