Operating Instructions (18-0015) AM-48 Test Set
0015-S077-10
In order to allow the transfer of timed test information into non-
volatile memory, the AM-48 power will not time-out during a
timed study. The time-out timer restarts at the end of a timed
study.
Level Display . There is only one level setting and it is stored in
volatile memory. For convenience, the level display that shows this
value can be accessed from any SEND display. The level display is
always the second display in the scroll. To access the level display:
1. Set Switch 2 to <SEND>.
2. Set Switch 7 to <SHIFT>.
3. Rock Switch 6 to select any SEND mode.
4. Press [ETR/NEXT]
5. Level display will appear.
Remember that when the level value is changed, it changes the level
for all SEND signals, except for dialed tones (see ¶7.12.3 for
instructions to set touch tone level). When power is turned off, the
send level always defaults to 00.0 dBm. The level for dialed tones,
however, is stored in non-volatile memory.
Store/Recall . Up to 10 test setups, including parameter values, can be
stored in non-volatile memory. A stored test setup can be recalled,
avoiding the need to set cursors and re-enter parameter values for a
routine test. See ¶7.36 for instructions.
