Unit Description (18-0015) AM-48 Test Set
0015-S033-4
Note: The AM-47 Hand-held Printer includes its own cable, P/N
48-0079. The Printer Cable P/N 48-0078 is for connection
to the RS-232 port (25-pin female) of most other serial EIA
printers..
PRINTER JACK
<PRT>
EARPHONE JACK
<EAR>
AC ADAPTER
PLUG <DC 9V>
RJ11 MODULAR
JACK
4-WIRE RECEIVE
BANTAM JACK
4-WIRE SEND,
2-WIRE
BANTAM JACK
Figure 3-2. AM-48 Connectors
YELLOW
GREEN
RED
BLACK
RJ-11
CABLE 48-0049, 7 Ft
2.5 mm JACK
AC ADAPTER 70-0029, 6 Ft
EARPHONE 82-0005, 3 Ft
Figure 3-3. Standard AM-48 Cables
