AM-48 Test Set (18-0015) Unit Description
0015-S03
-
GREEN
RED
R
T
S
BLACK
CABLE 48-0062, 6 Ft
BANTAM PLUG
CABLE 48-0047, 6 Ft
BANTAM PLUG BANTAM PLUG
CABLE 48-0048, 6 Ft
BANTAM PLUG
310 PLUG
2.5 mm JACK
2.5 mm PLUG
4-WIDE
MODULAR
PRINTER CABLE 48-0079, 6 Ft
2.5 mm PLUG
DB25 PLUG
PRINTER CABLE 48-0078, 6 Ft
Figure 3-4. Optional AM-48 Cables
3.5 Switches
Figure 3-5 shows the location of the AM-48 switches. The functional
descriptions of the switches in this paragraph follows the same
numbering scheme as Figure 3-5.
Note: Throughout this manual, a switch position indicated on the
front panel is referred to with angular brackets, <>. For
example, <ABS> refers to the absolute measurement position
of Switch 2.
Switches are referred to by number throughout this manual.
See Figure 3-5 for ease of reference of switch numbers.
