AM-48 Test Set (18-0015) Self-Test Instructions
0015-S05
-1
5 SELF-TEST INSTRUCTIONS
5.1 General
Purpose . This section has two (2) objectives:
1. To practice the main AM-48 operating procedures.
2. To verify that the AM-48 is working properly.
General . Each test in this section is described and illustrated. In the
figures, circled
letters correspond to the steps of the written
description; circled
numbers identify the switches.
Note: Power is ON for the tests in this section. See Section 4
concerning connecting and turning on power to the AM-48.
5.2 Self-Test Setup
Self-Test Setup is depicted in Figures 5-1 and 5-2.
Cable Connection . The tests in this section are done with the AM-48
looped back on itself, not connected to any external equipment. Plug
in the Modular-to-Minigator Cable (48-0049) (supplied with the
AM-48), and connect the minigator clips as shown in Figure 5-1.
The signals sent (generated) through the send port are routed directly
back to the receive port.
