2. The POWER LED
blinks when power is ON and the battery pack
has been charged.
3. The SIGNAL LED lights when data is being received from the
AM-48.
Printing Mechanism . The printing mechanism is a dot matrix impact
type with a replaceable ribbon cartridge. It uses standard-width
adding machine paper. The ribbon cartridge and paper supply are
housed within the case (see Figure 3-9). The printout is in a
24-column format (see Figure 7-11 thru 7-13 for example printouts).
In order to conserve paper, no automatic space is made after a
printout. The paper can be advanced manually with the PAPER
ADVANCE button.
Table 3-3. AM-47 Hand-Held Printer Technical Specifications
CHARACTERISTICS SPECIFICATIONS
Input Signal Serial ASCII Code with 2-Wire Proprietary
Current Loop
Input Connector 4-Wide Modular Jack
Input Speed 300 Baud with 1500 Character FIFO Buffer
Print Type 6 x 8 Impact Dot Matrix
Paper 2.25”W x 1.8” Dia. Adding Machine Paper
Ink Supply Replaceable Inked Ribbon Cartridge
Characters per Line 24
Print Speed 0.7 Lines per Second
Power Internal NiCad Battery Pack with Built-In
Charger
Battery Life Approximately 10,000 Lines
Charge Time 8 to 14 Hours
Size 7.6”L x 3.4”W x 1.9”D
Weight 1.5 lbs.
Cables Printer Cable (48-0079), Supplied AC Adapter
(70-0029) (cables shown in Figures 3-3 & 3-4).
