Operating Instructions (18-0015) AM-48 Test Set
0015-S077-14
To send a variable
momentary tone, set the SEND cursor to QUIET and
set the level and frequency per instructions in ¶7.12.1 and 7.12.2.
Send the frequency from the QUIET SEND display by pressing the
number to which the tone is assigned. Momentarily press Switch 8 to
<X TONE> to send
momentary 2713 Hz tone (¶7.19).
To send a variable continuous tone, set the SEND cursor to VAR and
set the desired level and frequency per ¶7.15.
To send
continuous 1004 Hz, set the SEND cursor to 1004 (¶7.14). To
send continuous PAR, set the SEND cursor to PAR (¶7.18).
To send a pre-programmed set of slope frequencies, set the SEND
cursor to 3TONE (SLOPE
for the AM-48E) (see ¶7.16).
To send variable sweep set the SEND cursor to SWEEP (¶7.17).
7.11 Send Quiet
1. See Figure 7-1. Set switches per the SWITCH SETUP illustration
and the SEND cursor per the menu illustration.
2. A Quiet termination display will appear, “_ _ _ _ _ _ _ _”,
confirming that the AM-48 is quiet terminated.
